Specifications
Equipped With
Preliminary Specifications:
Screen Diameter - 12"
Stage Table Size - pending
Stage Travels - pending
Stage Capacity - 15 Lbs.
Stage Glass Insert - pending
Max Height of Specimen - 4"
Chart Rotation - 360º with digital display
Illumination - High/Low Intensity Control , 24v / 150w
Image Type - Erect and Unreversed
Electrics - 1/60/110 VAC
Unit Dimensions - 16.1" x 25.5" x 42.1"
Unit Net Weight - Approx 245 Lbs.
Shipping Weight - Approx 450 Lbs.
Equipped with:
Quadra Chek 2000 Digital Readout
Built-In Digital Protractor with Fine Rotation Knob (reading to 1 minute arc).
Linear Encoders / Min Reading 0.001" mm / .00005"
Built-In Surface Illumination
Manual 3-Position Lens Turret with PENDING
Screen Hood
Instruction Manuals
Specifications subject to independent verification by the buyer.
Availability pending.
