Specifications
Equipped With
Specifications:
Screen Diameter Viewing Area - 16"
Workstage Size - 17.75" x 4.75"
Measuring Travels - 10" x 6"
Focus Travel - 3"
Table Load Capacity - 110 Lbs.
Table Helix Adjustment - ± 15º
Electrics - 1/60/115 V
Dimensions - 22" x 44" x 37.2"
Net Weight - 275 Lbs.
Crated Shipping Weight, Approx - 540 Lbs.
Equipped with:
Quadra Chek 2000 Digital Readout
Fiber Optic Edge Sensing / Detection
Electronic Digital Protractor Display
Fiber Optic Surface Reflection
Glass Crosshair Chart with Chart Clips
Quick Release Table for Fast Positioning (X-Axis)
(1) Magnification Lens - TBD
Vertically Corrected Image
Cabinet Base
Necessary Manuals
Availability pending - Machine needs cleaned and serviced.
Specifications subject to independent verification by the buyer.
Prep and crating charge $400 if required for transport.
