Specifications
Equipped With
Features:
In-Line Design
Screen viewing area diameter - 31.5"
Table Travels - 20" x 10"
Focus Adjustment - 3"
Table Load capacity 660 Lbs.
Helix Angle Table Adjustment +/- 15 degs
Built-In Push Button Lens Turret
(3) Lenses 10x, 20x, and 50x
High Power, Fan Cooled Mercury Arc Projection
Power Vertical Table Elevation with Joystick Control
Manual Longitudinal Travel
Table Weight Capacity 500 Lbs.
Digital Angle Display
Erect and Unreserved Image
Integral Hood with Overhead Visor & Curtain
Dimensions (less dro and visor) 38.6" LR x 84.7" FB x 76.8" H
Notes:
Availability Pending.
Projection lighting only. No surface illumination.
Specifications subject to independent verification by the buyer.
Seller will prep for shipment. Buyer responsible for shipping.
