Specifications
Equipped With
Specifications:
Travels - 100" x 60" x 28"
Table Size - 60" x 96"
Feed Rate - 500 ipm, max
Rapid Traverse Rate - 1000 ipm
Max Weight on Table - 5000 lbs.
Distance Spindle To Table - 4" min to 32" max
Spindle Speed - 50 to 8000 rpm
Spindle Taper - CT40
Spindle Motor (1 min/ 30 min) - 24/15 HP
ATC - 24 Pocket Carousel
Tool Change Time - 7 Seconds Tool to Tool
Max Tool Diameter - 4"
Max Tool Length - 11"
Max Tool Weight - 10 Lbs.
Dimensions (Floor Space Required) - 265" x 148" x 134"
Weight, Approx - 15,000 Lbs.
Equipped with:
Cent 7 CNC Control
Conversational Plus G & M Code Programming
3D Part and Tool Path Graphics
3.5" Floppy Drive Replaced with Emulator
Specifications subject to independent verification by the buyer.
Factory literature for reference only. There may be discrepancies.
Seller can load by appointment. Must transport on air ride truck / trailer.
