Specifications
Equipped With
Specifications:
X axis travel - 20"
Y axis travel - 16"
Z axis travel - 20"
Table size - 26" x 16"
Allowable table load - 800 lbs
T-Slot size - 0.63"
Spindle gage line to table distance - 6.5" to 26.5" '
Column to spindle center - 17.25"
Spindle taper - CT40
Spindle speed - 8000 rpm
AC spindle motor - 18/12 HP
Automatic tool changer - 20 tools
Rapid traverse rates XYX - 1000 ipm
Max cutting feed rates - 500 ipm
Machine height - 102.5"
Floor space required - 100" x 78"
Machine weight - 7500 lbs
Equipped with:
Milltronics 8200-B Series CNC Control
20 pocket double arm ATC
8000 RPM spindle
12" LCD color display
Full enclosure
Flood coolant
Rigid tapping
Tooling and vises are not included.
This machine is located in Salem OH shop. Seller can load.
Fully functional and in operation every day.
Offered on consignment. No warranty or return privilege.
Specifications subject to independent verification by the buyer.
