Specifications:

• Table Size – 10” x 50”
• Longitudinal Travel – 36”
• Cross Travel – 16”
• Knee Vertical Travel – 16”
• Quill Travel – 5”
• Spindle Taper – R8
• Spindle Motor – 3 HP
• Spindle Speeds, Infinitely Variable – 60 to 4200 rpm
• Quill Diameter – 3.375”
• Quill Power Feeds (3) – 0.0015”, .003”, .008”
• Head Tilt Forward & Backward – 45 Degrees
• Head Tilts Left & Right – 90 Degrees
• Ram Swivel – 360 Degrees
• Max Workpiece Weight – 750 Lbs.
• Electrics – 3/60/220v
• Machine Dimensions, Approx 68” x 59” x 85”
• Weight, Approx – 2850 Lbs.
